Replacement Electronic Safe Lock, with Solenoid Safe Lock Mechanism

1. The electronic lock can be set with 2 sets of passwords, management code and user code.The password length is fixed to 6 digits.

2. Factory state: management password 1-2-3-4-5-6, no user code.

3. When the system is powered on, there will be a beep of "beep"; if there is a delay of 5S or the password is wrong in any process, the red light will flash twice, the buzzer will sound, and then the system will exit and enter the sleep state.

4. Password (the same way as management code and user code) setting:

• Enter 0-0-0-0-0-0, directly enter the password setting mode, and there are indicator lights and sound reminders. (yellow light on)

• Enter the original 6-digit password (yellow and red lights are on at the same time when correct)

• If the original password is correct, continue to enter the new 6-digit password, repeat 2 times. If the new password is the same twice, the new password is set and exit the password setting mode. If the new password is entered differently twice, the setting is unsuccessful. (After entering the new password for the first time, the red light and yellow light will be on at the same time.

• If the original password is entered incorrectly, it will exit the password setting mode,and there will be indicator lights and sound prompts.

5. Add/delete user password settings:

• Enter 0-0-0-0-0-0 to enter the password setting mode, with a yellow light indicator and a sound reminder.

• Enter the management password, if it is correct, you can go to the next step, and if it is wrong, exit.

• Enter 1-1-* (asterisk) to enter the user code setting. Enter the 6-digit user password and repeat the confirmation once.

• Enter 2-2-* (asterisk) to delete the user password.

6. Enter the password. After entering the 6th digit of the correct password, open the lock directly---the electromagnet down for about 5S. (No * or # confirmation required.)

7. In the password setting and adding or deleting mode, if the 6th digit of the password is correct,go to the next step directly without * or # confirmation. There are indicator lights and sound prompts during the connection process.

8. Other conventional indicator lights and key sound prompts are handled in the usual way.

9. Password initialization

If you forget the password, you can press the escape button (if it is not equipped with this button, please short-circuit the two pins on the vacant socket on the circuit board in the box),after hearing the voice prompt, the management password will be restored to 1-2 -3-4-5-6, no user code.

10. Password test (error code) function

If the number of consecutive wrong password input is greater than or equal to 3 times, the system will be locked for 5 minutes, and the buzzer will beep once when the key is pressed (longer than the normal key tone). After 5 minutes, the system returned to normal. The number of errors will be cleared after entering the correct password to open the door.
